V TYPE BALL VALVE

V TYPE BALL VALVE
V TYPE BALL VALVEV TYPE BALL VALVEV TYPE BALL VALVE
group name
V Type Ball Valve
Min Order
1 piece
brand name
OVIKO
update time
Fri, 12 Apr 2019 17:38:13 GMT

Packging & Delivery

  • Min Order1 piece

Briefing

Oviko V type ball valves design meet latest pipeline high engineering evolution, focus on industrial valve solutions.

Detailed



Product Name : V TYPE BALL VALVE

Size & Pressure : 150# DN50-DN1200 / 300# DN50-DN1200

PDF Download:V-Type-Ball-ValveV-Type-Ball-Valve
Page Key : V TYPE BALL VALVEHits : Date Time : 2009-3-30



Product Details
V TYPE BALL VALVE ( SEGMENTED BALL VALVE)

Applicable for the fluid containing fibers,the high-viscosity fluid containing solid particles,the special fluid control and flow regulating,it can also be used as the isolating valve for its reliable sealing.It is widely employed in chemical industry,paper-making,petroleum,electric power,etc.It has excellent performance.

1.  Preeminent performance of adjustment control

The ball is of "V"pattern.At any position from full open to full close,it always keeps the standard geometry.The large adjustable extent is from 100:1 to 200:1,the CV curve of discharge characteristic is similar to the percentage curve,which may realize the precise control of the flow.

2.  One piece body

One piece integral body,the strength is high,stress deformation resistance is strong,has no central flange,confinement reliability is improved,has no bending transition at the flow passage,not accumulate,not block,has little influence upon the fluid.

3.  eliable seat sealing

The sealing surface build-up welding is handled by hard facing and employ the advanced seat grinding technology and griding ball technology to make V type ball valve have reliable sealing performance which can achieve the V sealing grade of ANSI B16.104 specified.The special requirement can achieve VI grade.

4.  Ball

The ball hard surface handled by STL,tungsten,etc.Both the two ends are V pattern,which is easy to precise control for flow also can realize the shearing action for the fluid containing cellulosic,the high-viscosity fluid containing solid particles when shutting.

5.  Sealing packing

The stem adopts the adjustable jam type packing of V type PTFE or RPPL.Ensure that has reliable sealing and no outleakage under the middle and high temperture.

6.  Drive&Positioner

OVIKO V TYPE BALL VALVE complement using driver adopts the adjustable manual exerciser,pneumatic driver(with positioner) and adjustable electric driver.
